Reticle Grid 1.6mm Squares 100 Total
Reticle Grid 1.6mm Squares 100 Total
Reticle Grid 1.6mm Squares 100 Total

Reticle Grid 1.6mm Squares 100 Total

No reviews yet Write a Review
KR-494 glass eyepiece reticle. Grid 1.6mm x 1.6mm. 100 squares total (10 x 10) 0.16mm squares. Without numbers and letters. Diagonal equals 2.26mm. Available in… Read more
SKU: KR494
Square Size: 0.16mm
Measurement: Metric
$125.00
Hurry up! Current stock:
icon Share icon Share
Request a quote
Description

KR-494 glass eyepiece reticle. Grid 1.6mm x 1.6mm. 100 squares total (10 x 10) 0.16mm squares. Without numbers and letters. Diagonal equals 2.26mm. Available in a variety of diameters, select when ordering.

  • Each Square: 0.16mm x 0.16mm when using 1x objective
  • Lines: Chrome deposition
  • Chamfer: 0.010" - 0.020"
  • Flatness: 2 waves or better
  • Centering: Within 0.005"
  • Glass Thickness: 1.5mm+/-0.2mm
  • Surface Quality: 20/10
  • Parallelism: 2 min.

NOTE: This is a special order product. Please allow 2-3 weeks for delivery. This item is not returnable.
